LINE 11W-3000K-36-DIM-BLACK
BL02112002
Recessed led downlight, square white low luminance black. contemporary and architectural, it is dimmable on triac. low glare UGR<19
LED ceiling light, architectural recessed, triac dimmable
LED ceiling light, architectural recessed, triac dimmable
BL02112002
Data sheet
- Yes
- IP
- IP40
- IRC
- >90
- Dimmable
- Yes
- IK
- IK06
- Energy efficiency class
- F
- Warranty (years)
- 3
- Total power (W)
- 11
- Electric class
- III, II with power supply
- Power factor
- >0.9
- Rated voltage
- 230V
- Light beam spread (°)
- 36
- Luminous flux (lm)
- 600
- Color temperature
- 3000K
- Safety group (EN62778)
- RG1
- Unified Glare Rating (UGR)
- < 19
- Driver included
- Yes
- Including the light source
- Yes
- Tiltable
- Non
- Length (mm)
- 75
- Width (mm)
- 75
- Height (mm)
- 51
- Weight (kg)
- 0.26
- Min. recessed diameter (mm)
- 67
- Max. recessed diameter (mm)
- 67
- Recessed diameter
- 67
- Product color
- Black
- Use temperature range
- -20°... +45°C
- Connection type
- Connector on the product
- IP (value)
- 40
- Body materials
- Aluminium
- Diffuser materials
- PC
- Life span duration
- L70 à 25° : 50 000 h
- Recessed depth under BA13 (mm)
- 60
- Recoverable
- Non recouvrable
- Dimmable values
- Triac
- Network frequency
- 50Hz
- Initial SDCM
- SDCM< 4
