HIBAY CCT-150W-110W-75W-40W-3CCT-WHITE

BL111506510
Industrial led frame, 3 temperature colors (3000K, 4000K and 5500K) and 4 powers (150W, 110W, 75W, 40W). 130 lm / Watt!
BL111506510
BE-LED

Data sheet

IP
IP65
IRC
>80
Dimmable
Non
IK
IK08
Energy efficiency class
D
Warranty (years)
5
Total power (W)
40 / 75 / 110 / 150
Electric class
I
Power factor
>0.95
Rated voltage
230V
Light beam spread (°)
90
Luminous flux (lm)
20000
Color temperature
4000K, 3000K, 5000K
Safety group (EN62778)
RG1
Driver included
Yes
Including the light source
Yes
Light source type
SMD
Tiltable
Non
Height (mm)
200
Weight (kg)
2.32
Product color
White
Use temperature range
-25°... +45°C
Connection type
Fil à connecter
IP (value)
65
Body materials
Aluminium
Diffuser materials
PC
Life span duration
L80 à 25° : 50 000 h
Cable length
20 cm
Recoverable
Non concerné
Dimmable values
1-10V
Tilt angle
90
Network frequency
50Hz
Initial SDCM
SDCM< 4
Max. lamp per B10A circuit breaker
5
Max. lamp per B16A circuit breaker
7
Max. lamp per C16A circuit breaker
10
UKCA certified
Yes
