TF145-SKYLED-150W-IP65-90D-5000K-0-10V-WH
BL111506506
Industrial LED armature 140lm/Watt - CEE eligible, linear light distribution optimized for aisles between racks or manufacturing or assembly workshops.
BL111506506
Data sheet
- Yes
- IP
- IP65
- IRC
- >80
- Dimmable
- Yes
- IK
- IK08
- Energy efficiency class
- E
- Warranty (years)
- 5
- Total power (W)
- 150
- Electric class
- I
- Power factor
- >0.95
- Rated voltage
- 230V
- Light beam spread (°)
- 90
- Luminous flux (lm)
- 21300
- Color temperature
- 5000K
- Safety group (EN62778)
- RG1
- Driver included
- Yes
- Including the light source
- Yes
- Light source type
- SMD
- Tiltable
- Non
- Length (mm)
- 1160
- Width (mm)
- 171
- Height (mm)
- 65
- Weight (kg)
- 3.86
- Product color
- White
- Use temperature range
- -35°... +40°C
- Connection type
- Fil à connecter
- IP (value)
- 65
- Body materials
- Aluminium
- Diffuser materials
- PC
- Life span duration
- L80 à 25° : 50 000 h
- Cable length
- 100 cm
- Recoverable
- Non recouvrable
- Dimmable values
- 0-10V
- Tilt angle
- 90
- Network frequency
- 50Hz
- Initial SDCM
- SDCM< 4
