CIRCULAR-40W-3CCT-DIAM600

Data sheet

IP

IP20

IRC

>80

Dimmable

Yes

IK

IK04

Energy efficiency class

D

Warranty (years)

5

Total power (W)

40

Electric class

I with power supply, III

Power factor

>0.95

Rated voltage

230V

Light beam spread (°)

110

Luminous flux (lm)

3000, 3100

Color temperature

4000K, 3000K, 5700K

Safety group (EN62778)

RG0

Driver included

Yes

Including the light source

Yes

Light source type

SMD

Tiltable

Non

Width (mm)

35

Height (mm)

35

Weight (kg)

2

Weight (kg)

2.86

Product color

Black

Use temperature range

-20°... +45°C

Connection type

Fil à connecter

IP (value)

20

Body materials

Aluminium

Life span duration

L70 à 25° : 54 000 h, L90 à 25° : 24 000 h

Cable length

300 cm

Recoverable

Non concerné

Dimmable values

Dali, push dim

Network frequency

50Hz

Initial SDCM

SDCM< 4

Max. lamp per B10A circuit breaker

18

Max. lamp per B16A circuit breaker

29

Max. lamp per C16A circuit breaker

48
